Smart wooden spoon machine

The machine adopts gas and hydraulic pressure cylinder, the use of compressed gas as a power source, use the size of the supercharger cross-section of different compression ratio, and the energy conservation principle of PASCAL (pressure constant, when compression area has change from big to small, the pressure will change with different sizes), to increase the air pressure to dozens of times the pressure effect.With high pressure, low noise, stable running, etc,This machine has a temperature regulation, time adjustment, pressure adjustment, counting, and other functions, suitable for wooden spoon shape. Compare with the manual hot press machine, the CNC automatic machine can largely improve the production speed, saving labor cost.

Keyword：

spoon fork knife hot press forming machine wooden spoon making machine disposable cutlery making machine wooden cutlery making machine disposable wooden spoon manufacturing machine disposable wooden spoon fork and knife machine Spoon Making Machine wooden cutlery machinery wooden spoon manufacturing process

Classification：

Wooden spoon fork knife production line

Tel：

0086 18342001808（WeChat/WhatsApp）

Contact

Smart wooden spoon machine

1.Technical Parameters

Machine weight：1300Kg

Specification：6500*2500*1900mm

Voltage：220/380/415v or as per customer requirement,50Hz

Power:18KW

Efficiency :7000-10,000pcs/hours

Warranty: 1 years

Lead time: 30 days for full automatic / with ready machine in stock

Technical supporting: Full technical supporting to ensure customer always get

2.Standard Components Instruction

Name	Brand
PLC	LK
Cylinder	JX
pneumatic element	AirTAC
Guide Rail	HN
Servo Motor	PFDE

3.Equipment Process and Flow chart

1. Soakingthe head of a flat wooden spoon in 35 to 55 degrees of water.
2. 10-20 seconds to dry water, putinto the material stock bin.
3. Automatically feeding material into the mold.
4. Mold preheating temperature into170 °-180 °
5. Pressure to forming, machine holding 14-16 seconds
6. Equipment output 16000-20000pcs /hour
7. Machine 24 hours running

CNC automatic rotary cutting machine

GLC Fully Automatic Wooden Cutlery Making Machine Disposable Wooden Knife, Fork and Spoon Production Line
