Automatic Disposable Wooden Spoon Hot press machine With Steam cutlery production machine

High Speed Disposable Wooden Spoon Making Machine with Steam，wooden cutlery production line，wooden spoon making machine suppliers in india， wooden knife fork spoon making machine.ice cream wood spoon making machine line.

Keyword：

hot press machine Steam type wooden cutlery making machine wooden spoon machine wooden spoon making disposable cutlery making machine wooden fork making machine wooden spoon hot pressing machine wooden spoon production machine

Classification：

Wooden spoon fork knife production line

Tel：

0086 18342001808（WeChat/WhatsApp）

Contact

Automatic Disposable Wooden Spoon Hot press machine With Steam cutlery production machine

The machine adopts gas and hydraulic pressure cylinder, the use of compressed gas as a power source, use the size of the supercharger cross-section of different compression ratio, and the energy conservation principle of PASCAL (pressure constant, when compression area has change from big to small, the pressure will change with different sizes), to increase the air pressure to dozens of times the pressure effect.With high pressure, low noise, stable running, etc,This machine has a temperature regulation, time adjustment, pressure adjustment, counting, and other functions, suitable for wooden spoon shape.

Compare with the manual hot press machine, the CNC automatic machine can largely improve the production speed, saving labor cost.

Technical Parameters

Machine weight：3400Kg

Specification：6500*4500*1900mm

Voltage：220/380/415v or as per customer requirement,50Hz

Power:18KW

Efficiency：16000-20,000pcs/hours

Warranty: 1 years

Lead time: 45 days for full automatic / with ready machine in stock

Technical supporting: Full technical supporting to ensure customer always get

Standard Components Instruction

Name	Brand	Remarks
PLC	LK
Cylinder	JX
pneumatic element	AirTAC
Guide Rail	HN
Servo Motor	PFDE
Supplier could change equal brand as per market availiability

Equipment Process and Flow chart
1. Soakingthe head of a flat wooden spoon in 35 to 55 degrees of water.
2. 10-20 seconds to dry water, putinto the material stock bin.
3. Automatically feeding material into the mold.
4. Mold preheating temperature into170 °-180 °
5. Pressure to forming, machine holding 14-16 seconds
6. Equipment output 16000-20000pcs /hour
7. Machine 24 hours running

Disposable Wooden Spoon And Fork Making Machine

Dying &polisher
